Bulk feed truck is also called feed truck, feed tank truck, bulk feed transport vehicle, bulk feed delivery truck, bulk feed transporter truck, etc. It is a special transport vehicle made of high-quality, high-strength steel plate welded forming tanks and equipped with electric or hydraulic auger unloading system on the basis of various types of trucks or second-class chassis. Bulk feed truck consists of the chassis, the loaded feed tank, the discharge auger system and the electro-hydraulic operating system.
Optional feed tank capacity: 12cbm to 42cbm bulk feed truck, 40cbm to 70cbm bulk feed trailer.
Optional quantity of compartments: 2-5 warehouses, 3 warehouses as our standard.
Optional brands of chassis: Dongfeng, FOTON, JAC, SHACMAN, HOWO bulk feed trucks for choose.
Discharge method: Electric or hydraulic screw conveyer discharge system, electric can be powered by a generator.
Specifications of DONGFENG DLK 4x2 12m3 Bulk Feed Truck:
|
Item |
Parameter |
|
Production name |
Dongfeng DLK Bulk Feed truck |
|
Vehicle model |
CLW5110ZSLE5 Bulk Feed truck |
|
Engine |
Engine model: CY4SK251 |
|
Engine manufacturer: Dongfeng Chaoyang Diesel Engine co., LTD |
|
|
Exhaust: 3856ml |
|
|
Power: 105kw |
|
|
Chassis model |
EQ1111GLJ |
|
Tire |
Tire specification: 8.25-20 |
|
Number of tire:6 |
|
|
Axle |
Number of axles: 2 |
|
Axle-load: 4825/6670 |
|
|
Wheel base(mm): 3800 |
|
|
Traction system |
4*2 |
|
Tank fact cubage(cbm) |
12 |
|
GVW(kg) |
11495 |
|
Curb weight(kg) |
5310 |
|
Overall dimensions(mm) |
7100×2200×3400 |
|
Feed tank dimensions(mm) |
4300×2380×1900 |
|
Compartment |
3 |
|
F / R track base(mm) |
1760/1640 |
|
F/R overhang(mm) |
1210/2690 |
|
Approach / departure angle(°) |
22/14 |
|
Max speed(Km/h) |
95 |
|
Equipment |
Equipped with chassis, feed tank, feed discharge screw , electrical operating system |
